Colnago V4 Ultegra Di2 Disc VDDK Road Bike

The same thrills of V4Rs, but with a more accessible configuration.

Lightness and responsiveness, with Colnago charm

The Colnago V4 is an all-round bicycle, a bike that is extremely fun to ride and has a clean and refined design. The frame is a monocoque which is stiff, solid, reactive, and which enjoys the same carbon layup R&D and aerodynamic studies that led to the realization of the V4Rs.

Quality carbon and fittings designed to offer an excellent level of performance make the V4 a perfectly balanced bike in every respect. The design combines technical features with light and aerodynamic details.

Please note that the specifications supplied by the manufacturer may be impacted by component stock availability at the factory assembly stage.

This bike will be shipped un-built in the manufacturer supplied packaging. We strongly recommend that this bike be assembled by a qualified bike mechanic or bike shop.

Any assembly undertaken without professional assistance, and subsequent damage from faulty assembly, is at the customers risk.

An assembly service for any "Completed Bike" purchases made through our click and collect service, can be arranged for an additional cost. Reach out to our customer service team for additional information.

Specifications

Details

Series: V Series

Model: Colnago V4

Frame kit

Frame (material): Monocoque carbon.

Fork (material, section notes): Carbon fork for disc brakes, integrated cables, 1"1/8 section

Headset: ACROS ss 1"1/4 35x47x7 bearing

Seatpost: Carbon seatpost, 0.15 offset, "D-Shape" section

Through axles: Diameter: 12 mm. length 100 mm (front) - 142 mm (rear)

Drivetrain (Ultegra not pictured)

Shifting system: Shimano Ultegra R8170 Di2 Disc

Front derailleur: Shimano Ultegra: Shimano FD-R8150

Rear derailleur: Shimano Ultegra: Shimano Shadow RD-R8150

Chain: Shimano Ultegra: Shimano CN-M8100 12V

Crankset: Shimano Ultegra: 52-36T

Cassette: Shimano Ultegra: 11-30 12v

Bottom bracket: T47

Crank length:

Sizes 420 - 485: 170 mm

Sizes 510 - 530: 172.5 mm

Sizes 550 - 570: 175 mm

Brakes

Brakes: Shimano Ultegra R8170, 160 mm Front / 140 mm Rear, RT-CL800 rotors

Disc size: 160 mm Front/ 140 mm Rear

Brake lever: Shimano ULTEGRA ST-R8170

Brake caliper: Shimano ULTEGRA BR-R8170

Wheels

Wheels: Fulcrum Racing 600 DB - Tubeless ready

Material: Rims: aluminium, Spokes: stainless steel.

Rim height: Front: 24 mm; Rear: 24 mm

Internal channel width: 20 mm

Hubs: Aluminium, Sealed Cartridge Bearings

Through axles: Front: HH12-100 - Rear: HH12-142

Tyres: Pirelli P7 Sport 28 mm

Maximum tyre size: 32 mm (nominal width)

Components

Saddle: SELLE ITALIA NOVUS BOOST EVO

Handlebar: COLNAGO R41 (carbon)

Sizes 420 - 485
Width: 400 mm

Sizes 510 - 530
Width: 420 mm

Sizes 550 - 570
Width: 440 mm

Stem: Colnago SR10

Size 420
Length: 90 mm

Size 455
Length: 100 mm

Sizes 485 - 510
Length: 110 mm

Sizes 530 - 550
Length: 120 mm

Size 570
Length: 130 mm

Handlebar Tape: Colnago Grip Black

Bottle cage: Colnago Matt Black (1x)
