Ritchey Frameset Road Logic Disc Green With White Logo

Steeped with more than 50 years of frame-building heritage, innovation, exploration, and lots of riding, the classic lines of this beautiful steel frame and carbon fiber fork unite with modern building techniques and proven materials to deliver a contemporary bicycle that’s wonderfully comfortable for long days in the saddle, nimble and stiff enough to win the sprint for that sign, and adequately adaptable to endure roads that might lack proper pavement.

The Road Logic Disc frame is built with a heat-treated and triple-butted Ritchey Logic tubeset designed specifically for the Road Logic. It features aggressively short-butted sections optimized for TIG welding that save weight and improve ride quality. The frameset also includes a Ritchey WCS Carbon Road Fork for precise handling and responsiveness.

Updated for 2024, this modern classic now sports compatibility with Shimano’s newest Di2 semi-wireless groupsets. A new drive side dropout design allows for concealed wire routing from the battery in the seat tube, through the bottom bracket area into the chainstay where it makes a stealthy exit to the rear derailleur. But mechanical shifting fans, rejoice - the Road Logic Disc frame retains cable stops for mechanical groupsets. On the non-drive side chainstay sits a new one-piece truss design for flat mount brakes - providing as much stiffness and strength of previous mounts while reducing chainstay weight significantly.

With purpose-driven design, unyielding attention to detail, and modern features, the new Road Logic Disc almost telepathically delivers an amazing ride experience unlike any other bike. It’s fast, nimble, comfortable, and perfectly suited for wherever your rides take you.

Tech Specs

FRAME

• Material: heat-treated, triple-butted Ritchey Logic steel tubing - TIG welded
• Ultra-light forged and machined straight 1-1/8" headtube
• Electrophoretic Deposition (ED Coat) treated for corrosion resistance
• Seat tube clamp size28.6mm (2.5Nm max for derailleur clamps and chain guides)
• 27.2mm seat tube with integrated seat collar (max torque setting: 6Nm)
• Bottom bracket: 68mm - English threaded
• 142mm spacing (12mm alloy thru-axle included)
• Crankset min/max ring size - single: 36 to 50t / double: 46/30t to 53/39t
• Can accommodate 1X or 2X chainrings
• Chainline: 49mm
• Bottle cage mounts: 2
• Stealth wire routing for semi-wireless Di2 groupsets
• Includes stops/guides for brake hoses and mechanical groupsets
• External cable routing
• WCS headset included (upper IS42/28.6 - 16mm stack height | lower IS42/30)
• Replaceable stainless-steel derailleur hanger

FORK

• Ritchey WCS Carbon Disc Road Fork included
• 1-1/8" straight steerer with integrated 45-degree crown race
• Steerer length: 300mm
• Axle-crown: 371mm
• Rake/Offset: 46mm
• 100mm spacing (12mm alloy thru-axle included)
• 30mm maximum spacers below stem

TIRE COMPATIBILITY

• Wheel and tire compatibility: 700 x 30c tire clearance (depending on tire/rim manufacturer)
• Frame max spacing: 39mm
• Fork max spacing: 40mm

BRAKE COMPATIBILITY

• Flat-mount brakes front and rear: 140mm (160mm max - adaptors available separately)
• Frame flat-mount bracket height: 10mm

DETAILS

• Sizes: 51 / 53 / 55 / 57 / 59cm
• Frame weight: 1,940g (size 55 - w/o thru-axle)
• Fork weight: 420g (with uncut steerer / not including axle)
• Color: Nigiri
